After selecting the desired configuration, users can confirm and update the design to allow TENADO METAL 3D to display the corresponding screw connection in the 3D live model. If the connection fits, it can be saved as a favorite and reused for later projects. This saves a lot of time in planning and design stages, especially for large projects.
Finished design data is transferred to the appropriate evaluations to be accessed and shared at any time by relevant parties. In this way, TENADO will be familiar to metal designers accustomed to working with the software for the metalworking industry.
However, thanks to these automations, TENADO provides faster and more efficient design solutions than standard software tools. The new screw connection generator can be used universally for any project requiring bolt fasteners, such as a railing on a beam, a connecting element in steel construction, or a head plate that fastens beams to supports. No matter what you use these new TENADO METAL 3D tool for, they have the potential to speed up design, improve customization, and reduce error rates in projects of any size.
Another time-saver: the new function for filling contours. This makes planning and designing fillings, railings, stages, or platforms easier than ever. With just a few clicks, you can automatically fill defined contours with profile bars while still leaving plenty of room to customize the results as needed.
Many factors can be adjusted to match the needs of the project:
All important details are saved during the design process and can be found in the parts and sawing lists. Simply share the analysis and make collaboration with colleagues easy. The new “Fill with bars” tool makes 3D metal structure design more streamlined, cost-effective, and error-free.
Master metalworker and TENADO METAL 3D user Lukas Brohammer presents the new “Fill with bars” function in this video.
The update for TENADO METAL 3D provides increased efficiency, greater design flexibility, and practical new functions to modern metalworking workflows. Metalworkers and designers rely on powerful 3D CAD software that significantly simplifies and accelerates daily design tasks. TENADO provides and updates these features with competitive new functionalities, helping you and your team improve your project workflow from start to finish.
Efficient design and modeling is easier than ever with TENADO METAL 3D. Contact our team today to experience TENADO METAL 3D live, free of charge and without obligation.
